| Item | Unit | Data | Note |
|---|---|---|---|
| Max swing over bed | mm | 800 | |
| Max cutting length | mm | 1000 | |
| Max diameter of workpiece | mm | 219 | Electric chuck |
| Spindle bore diameter | mm | 240 | |
| Spindle bore diameter | mm | 260 | Hydraulic chuck |
| Chuck | Chuck diameter and type | Φ630 electric chuck（dual chuck system） | |
| X-axis rapid feed rate | m/min | 4 | |
| Z-axis rapid feed rate | m/min | 8 | |
| X-axis travel | mm | 300 | |
| Z-axis travel | mm | 1000 | Electric chuck |
| Tool bar type | SLD21004N | Four vertical | |
| Workpiece size | mm | φ114~φ219 | Electric chuck |
| Overall dimensions | mm | 3792×1928×2060 | 1000 |
| Accuracy | IT7 | ||
| Machining flatness | 0.030 mm /φ400 mm | ||
| Machining roughness | Ra1.6μm | ||
| Positioning accuracy | X-axis 0.03mm | ||
| Positioning accuracy | Z-axis 0.04 mm |
